Asrock Z690 Pro RS s1700 4DDR4 DP/HDMI M.2 ATX

Asrock Z690 Pro RS s1700 4DDR4 DP/HDMI M.2...

Product images are
for illustrative purposes only

154,40 €

The item is out of stock. If you would like to get a notification when item is in stock, please, use the function

Notify on arrival

Not available from
30.07.2024

Brand: ASROCK
01.ee Item Code:1923714
Product code: Z690 PRO RS
EAN:
  • 4710483935985
Warranty: 36 months


Dimensions 30.5 cm x 24.4 cm
Expansion slots 1 x PCIe 4.0 x 16
BIOS
  • 128Mb AMI UEFI Legal BIOS with multilingual GUI support
  • ACPI 6.0 Compliant wake up events
  • SMBIOS 2.7 Support
  • CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +1.8V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustme
    		•
    Form Factor ATX
    Graphics
  • Intel Xe Graphics Architecture (Gen 12)
  • Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers
  • Support for Compatible HDMI 2.1 TMDS with a maximum resolution of 4K x 2K (4096x2160) @ 60Hz
    		•
    Software
  • ASRock Motherboard Utility (A-Tuning)
  • ASRock Dragon 2.5G LAN Software
  • ASRock Polychrome SYNC
    		•
    Memory Type DDR4
    CPU Socket LGA1700
    RAID Yes
    Description Optimised VRM Design
  • Dr.MOS is an integrated power solution, optimised for voltage synchronisation in many applications! Compared to traditional MOSFETs, it intelligently delivers voltage to each phase, ensuring lower operating tempe
    		•
    SOUND CARD
  • 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
  • Supports Surge Protection
  • Nahimic Audio
    		•
    Model Z690 PRO RS
    Supported operating systems Windows 10
    Max Memory Size 128
    Chipset type Intel Z690
    Memory bus frequency 5000 MHz
    External connectors 1 x Flash BIOS Button
    Network interface
  • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
  • Dragon RTL8125BG
  • Supports Dragon 2.5G LAN Software- Smart Auto Adjust Bandwidth Control- Visual User Friendly UI- Visual Network Usage Statistics- Optimized Default Settin
    		•
    Number of DDR4 slots 4
    Other information
  • FCC, CE
  • ErP/EuP ready (ErP/EuP ready power supply is required)
  • CEC Tier II ready
    		•
    Accessories included
  • Quick Installation Guide, operation CD, I/O cover
  • 2 x SATA data cables
  • 4 x Screws for M.2 sockets
  • 1 x Bracket for M.2 socket;
  • 1 x Graphics card holder;
    		•
    Processor family Intel Core
    Chipset manufacturer Intel
    Max. number of SATA devices 8
    Detailed data on disk/drive interfaces
  • 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode Chipset:
  • 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes
  • 1 x Hyper M.2 Socket (M2_3,
    		•
    USB ports at back panel 6
    USB ports on motherboard 5
    COM connector / port No
    LPT connector / port No
    Onboard connectors 1 x Front panel audio header
    FireWire (IEEE 1394) No
    Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 2
    Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 2
