Digitus Converter RJ45->SC SiMo

The Media Converters from DIGITUS are the ideal solution for the migration of Copper and Fiber Network Signals. From now on, you are able to access the Fiber Technology and transfer network signals over several kilometers without renewing your whole Network Infrastructure. The huge variety of Products fulfil your individual needs. The intiutive operation guarantees a quick and easy Installation. The Link Fault Pass Through function offers a no-fear-networking. Your Network Administrator will be able to find and solve Network problems easily. Years of Experience and a wide range of products lets DIGITUS become a reliable Partner for your Network.
Weight & dimensions
200 g
Ports & interfaces
Connectivity technology Wired
Ethernet LAN (RJ-45) ports 1
Fiber ports quantity 1
DC-in jack Yes
Power
Input voltage 5 V
Power consumption (typical) 2.5 W
External power adapter Yes
Design
Internal Yes
Colour of product Black
LED indicators Activity, Link, Status
Packaging content
Y
Other Featuress
Transmission distance (max) 20 km
Product dimensions (WxDxH) 95 x 70 x 26 mm
Operational conditions
0 — 55 °C
Performance
Wavelength 1310 nm
Maximum transfer distance 20000 m
Fiber cable diameters supported 9/125 μm
Fiber mode structure Single-mode
Buffer size 128 KB
Tx power (max) -8 dBmW
Tx power (min) -15 dBmW
Rx power (min) -38 dBmW
Networking
Converter input interface 100Base-TX
Fiber optic connector SC
Networking standards IEEE 802.3, IEEE 802.3u
Converter output interface 100Base-FX
Ethernet interface type Fast
Ethernet LAN data rates 10, 100 Mbit/s
Duplex system Full, Half
Auto MDI/MDI-X Yes
